Automation:

Auto objective selector, electric XY platform, electric Z-axis control.

Electric control for fluorescence channels, light source, and light path switching.

Equipped with PFS (Perfect Focusing System).

Objective Lenses:

10X, N.A. 0.45, W.D. 4.0 mm.

20X, N.A. 0.80, W.D. 1.0 mm.

20X, N.A. 0.45, W.D. 8.2 mm (extra-long working distance).

40X, N.A. 1.15, W.D. 0.61 mm (water immersion).

60X, N.A. 1.42, W.D. 0.15 mm (oil immersion).

60X, N.A. 1.27, W.D. 0.18 mm (water immersion).

100X TIRF, N.A. 1.49, W.D. 0.16-0.09 mm.

Confocal Imaging:

4-channel lasers: 405 nm, 488 nm, 561 nm, 640 nm.

High-speed resonant scanning system.

Super-Resolution:

Super-resolution module.

Software deconvolution module.

Live-Cell Imaging:

Temperature control: 10/15°C below room temperature (chamber-dependent) to 60°C.

Camera:

Mono/color camera on the right side for widefield imaging.
